Pick and place machine: It is a device for high-speed, high-precision placement of components. It is the most critical and complex equipment in the entire SMT and production. The placement machine is a SMT device that uses patch devices. Now, the pick and place machine has evolved from an early low-speed mechanical placement machine to a high-speed optical centering placement machine, and it is a multi-functional, flexible connection. The modular development has accelerated the efficiency of the entire SMT production line, replacing the manual cost reduction device!

The SMT pick and place machine is a device for high-speed, high-precision placement of components, and is a key and complex device in the entire SMT. SMT pick and place machine is the use of SMT equipment in SMT production. Now, SMT pick and place machine has developed from the early low-speed mechanical placement machine to the high-speed optical centering placement machine, and to the multi-function, Modular development of flexible connections. In the SMT line, it is placed behind a dispenser or solder paste printer and is a device that accurately places surface mount components on the PCB pads by moving the placement head. Divided into manual and fully automatic. Generally speaking, it is a machine for mounting pin-chip electronic components to a circuit board.

The Yamaha pick and place machine, Yamaha SMT pick and place machine, Yamaha placement, Yamaha chip mounter, Yamaha chip shooter is one of the most common mechanical equipment in electronics manufacturing companies. The placement machine consists of a frame, an XY motion mechanism (ball screw, linear guide, drive motor), a placement head, a component feeder, a PCB carrier mechanism, a device alignment detecting device, and a computer control system. XY motion mechanism. The ball screw transmits power and achieves directional motion by rolling a linear guided motion pair. This type of transmission not only has its own small motion resistance, but also has a compact structure and high motion precision. Ensure the placement accuracy of each component. With the placement machine, there is no need to manually find the position welding assembly, saving a lot of time and cost. What matters is accuracy.
